Zamek antypaniczny - LPKQ60U2LGSZA2

Nr pozycji P00015097 - LPKQ60U2LGSZA2
Zamek z mechanizmem ze stali nierdzewnej w obudowie aluminiowej. Możliwa konfiguracja z certyfikatem EN179 z LPKQ U2 dla profili 40 i 60 mm z zaczepem SAKL, klamką 3006A-2 i cylindrem zamka 3012-54-STD. Dzięki temu rozwiązaniu możliwe jest bezpieczne wyjście z obiektu. Otwarcie bramki od zewnątrz jest możliwe tylko przy pomocy klucza. Płynna i dokładna regulacja rygli w zakresie 20 mm pozwala na idealną prace i bezpieczne zamknięcie. Skok nierdzewnego rygla o 23 mm zapewnia pewne zabezpieczenie. Do montażu polecamy szablon do wiercenia Drill-Fix.
Product specs
60056009701690059010SILV
P00015097-6005
Stainless steel superior anti-panic lock with aluminium housing. EN179 certified configuration possible with LPKQ U2 for 40 & 60 mm gate frames with SAKL keep, 3006A-2 handle and 3012-54-STD- cylinder. Escape or exit from inside is possible at all times by operating the handle. Mechanical access from the outside is always possible by operating the cylinder. The 20 mm continuous adjustability of the bolts allows a perfect latching / locking of the mechanism. A solid stainless steel deadbolt with a 23 mm throw guarantees a secure locking. For a fast and highly precise installation, we recommend using the Drill-Fix drilling jig.
P00015097-6009
Stainless steel superior anti-panic lock with aluminium housing. EN179 certified configuration possible with LPKQ U2 for 40 & 60 mm gate frames with SAKL keep, 3006A-2 handle and 3012-54-STD- cylinder. Escape or exit from inside is possible at all times by operating the handle. Mechanical access from the outside is always possible by operating the cylinder. The 20 mm continuous adjustability of the bolts allows a perfect latching / locking of the mechanism. A solid stainless steel deadbolt with a 23 mm throw guarantees a secure locking. For a fast and highly precise installation, we recommend using the Drill-Fix drilling jig.
P00015097-7016
Stainless steel superior anti-panic lock with aluminium housing. EN179 certified configuration possible with LPKQ U2 for 40 & 60 mm gate frames with SAKL keep, 3006A-2 handle and 3012-54-STD- cylinder. Escape or exit from inside is possible at all times by operating the handle. Mechanical access from the outside is always possible by operating the cylinder. The 20 mm continuous adjustability of the bolts allows a perfect latching / locking of the mechanism. A solid stainless steel deadbolt with a 23 mm throw guarantees a secure locking. For a fast and highly precise installation, we recommend using the Drill-Fix drilling jig.
P00015097-9005
Stainless steel superior anti-panic lock with aluminium housing. EN179 certified configuration possible with LPKQ U2 for 40 & 60 mm gate frames with SAKL keep, 3006A-2 handle and 3012-54-STD- cylinder. Escape or exit from inside is possible at all times by operating the handle. Mechanical access from the outside is always possible by operating the cylinder. The 20 mm continuous adjustability of the bolts allows a perfect latching / locking of the mechanism. A solid stainless steel deadbolt with a 23 mm throw guarantees a secure locking. For a fast and highly precise installation, we recommend using the Drill-Fix drilling jig.
P00015097-9010
Stainless steel superior anti-panic lock with aluminium housing. EN179 certified configuration possible with LPKQ U2 for 40 & 60 mm gate frames with SAKL keep, 3006A-2 handle and 3012-54-STD- cylinder. Escape or exit from inside is possible at all times by operating the handle. Mechanical access from the outside is always possible by operating the cylinder. The 20 mm continuous adjustability of the bolts allows a perfect latching / locking of the mechanism. A solid stainless steel deadbolt with a 23 mm throw guarantees a secure locking. For a fast and highly precise installation, we recommend using the Drill-Fix drilling jig.
P00015097-SILV
Stainless steel superior anti-panic lock with aluminium housing. EN179 certified configuration possible with LPKQ U2 for 40 & 60 mm gate frames with SAKL keep, 3006A-2 handle and 3012-54-STD- cylinder. Escape or exit from inside is possible at all times by operating the handle. Mechanical access from the outside is always possible by operating the cylinder. The 20 mm continuous adjustability of the bolts allows a perfect latching / locking of the mechanism. A solid stainless steel deadbolt with a 23 mm throw guarantees a secure locking. For a fast and highly precise installation, we recommend using the Drill-Fix drilling jig.
Kontynuuj zakupy
Specyfikacje
Opis
  • Prosta zmiana rygla górnego pod furtkę lewą lub prawą
  • Jeden obrót klucza powoduje skok rygla o 23 mm
  • Obsługa rygla dziennego za pomocą klucza
  • 4-otworowy montaż dwiema śrubami imbusowymi
  • Rozstaw rygli 60 mm
  • Regulacja rygli do 20 mm bez demontażu zamka
  • Mechanizm ze stali nierdzewnej
  • Testowany na 500 000 cykli
  • Obudowa wykonana zgodnie z ISO 9227 KTL. Testowana 1000 godzin w komorze z mgłą solną
  • Dostępna konfiguracja z certyfikatem EN179
  • Funkcja paniki E / Funkcja przełączania
Dostępny w następującyh kolorach RAL
