Surface mounted US Mortise cylinder gate lock (USA) - LUKY20J5LZCZM

Item No. P00015225 - LUKY20J5LZCZM
Surface mounted US Mortise cylinder gate lock (USA) for square 20 to 30 mm profiles with 3006M - Aluminium handle pair & ZCZ - Various colours
9005SILV
P00015225-9005
Surface mounted US Mortise cylinder gate lock (USA) for square 20 to 30 mm profiles in 9005 with 3006M - Aluminium handle pair & ZCZ
P00015225-SILV
Surface mounted US Mortise cylinder gate lock (USA) for square 20 to 30 mm profiles in SILV with 3006M - Aluminium handle pair & ZCZ
Continue shopping
Specifications
Specifications
  • ISO 9227 KTL / E-coated lock box withstands 1000 hours of salt spray test
  • Lock for 29 mm length Mortise profile cylinder (Schlage Keyway & Adams Rite Cam)
  • Fixing cylinder inch thread 6 mm
  • Easy left or right changing of the self-latching daybolt
  • 23 mm throw of the dead bolt, in 1 turn of the key
  • Key-operated self-latching bolt
  • Continuous adjustment of 10 mm for the bolts without removing the lock
  • 4-hole fixing with two hexagon socket head screws
  • Interchangeable with all Locinox locks
  • 80 mm lock box width
Available in following RAL-colours
